A business cannot truly ensure the performance of a product unless it has undergone objective testing. While there are many ways to create items using high-quality materials, there’s no guarantee that the product will continue to perform as expected over time without being thoroughly tested under real-world conditions. For instance, quality furniture manufacturers have developed methods involving machines and robotics to simulate usage, such as sitting on a chair thousands of times or pulling a drawer hundreds of thousands of times to confirm that the parts will function reliably over their expected lifespan.
When it comes to cable assemblies, quality testing is primarily done through a process called proof load testing. This method ensures that both the cable tensile strength and the connectors meet or exceed the expected performance standards. Even data cables undergo torsion testing because if components only met the bare minimum requirements, regular use could quickly surpass those limits. Cable assemblies often include fittings at both ends, which can sometimes be weaker points, even if the cable itself is strong enough to handle the intended load. This can lead to fittings slipping off or breaking, causing mechanical failure within your application.
### What is Proof Load Testing?
Proof load testing is a procedure used to verify the strength and durability of cable assemblies. The aim of proof loading is to identify any weaknesses in the assembly, such as slight line stretching, hardware slippage, or microscopic wire damage, without actually breaking the cable. During this test, each assembly is subjected to tension on a flat testing surface. The tension is usually applied at 60% of the rated breaking strength of the mechanical cable.
An assembly that passes the proof load test is then subjected to a separate destructive test to determine its actual breaking point. This second test ensures that the breaking point occurs significantly higher than what a typical user would apply. By confirming the breaking point, Sava's engineers can guarantee that the assembly will operate safely within established safety parameters. These associated tests with the proof loading methodology ensure that every Sava cable assembly meets the highest safety and performance expectations.
---
### The Proof Load Testing Process
1. **Preparation of the Cable Assembly:** Each assembly is carefully laid out on a flat testing surface.
2. **Application of Tension:** Tension is applied at 60% of the rated breaking strength of the mechanical cable to reach a minimum separation point under ideal conditions.
3. **Identification of Weak Points:** The goal is not to break the cable but to uncover any potential weak spots caused by poor quality or bad design under proof load conditions.
---
### Importance of Proof Loading
Proof load testing serves two key purposes:
1. **Ensuring Integrity:** It verifies that the cable assembly can handle more than the minimum expected performance, ensuring reliability and safety.
2. **Prestressing the Cable:** This process removes constructional stretch, reducing the need for frequent adjustments and maintaining proper tension in motion control systems.
After assemblies are proof loaded, minimal handling is recommended to preserve the prestressing effect. If maintaining specific tension levels is crucial for your application, we recommend reaching out to Sava's engineering team for more information.
Identifying and addressing weak points early through proof load testing helps prevent mechanical failures and ensures the overall performance and safety of cable assemblies.
### Sava's Expertise in Proof Load Testing
At Carl Stahl Sava Industries, we are leaders in proof load testing, adhering to ISO 9001:2015, FDA, ITAR, REACH, and RoHS standards. Our rigorous testing protocols and advanced techniques ensure that every cable assembly meets the highest standards of quality and durability. In addition to proof load testing, we also employ other methods like torsion testing for data cables. Our comprehensive testing and quality checks throughout production help deliver a top-quality product line that sets the benchmark for the industry.
Proof load testing is vital to ensuring the integrity, reliability, and performance of cable assemblies. Sava's cable experts are committed to maintaining the highest standards of quality through rigorous testing and continuous improvement. Contact us today to learn more about our custom cable solutions.
---
